GENERAL
Size: 6.8”(17.3 cm) H x 10.3”(26.2 cm) W x 8.2”(20.8 cm) D
Weight: 11.5 lbs (5.23 kg) with Multi-Function Cable and battery; 13.5 lbs (6.14 kg) with paddles
Design Standards: Meets or Exceeds UL Standards
ECG MONITORING
Patient Connection: 3, 5 or 12 -lead ECG cable, paddles or MFE Pads.
Bandwidth: 0.5-40 Hz (-3 dB) or 0.5-30 Hz; 0.05-150Hz diagnostic
ECG Size: 0.5, 1, 1.5, 2, 3 cm/ mV – display on monitor
Heart Rate: Digital display 0-3000 bpm ± 5%
DISPLAY
Screen Type: High-resolution display
Screen Size: 5.6"(14.2cm) diagonally
Sweep Speed: 25mm/ sec
Viewing Time: 4 seconds
Channels: 2
DEDIBRILLATOR
Waveform: Damped Sinusoid or Zoll Rectilinear Biphasic
Energy Selection: Selectable 1, 2, 3, 4, 5, 6, 7, 8, 9, 10, 15, 20, 30, 50, 75, 100, 150, 200, 300, 360 joules. (Delivered into 50 Ω load.)
Charge Time: Less than 7 seconds with new fully charged battery
Paddles: External anterior/ anterior adult and pediatric
|
